The Macina Style FS Prime is the first full-suspension step-through bike from KTM . Enjoy the unique comfort of a low step-through with a cushioned rear triangle. Together with the 100 mm suspension fork, every tour becomes a pleasure. Perfectly integrated, the damper literally disappears into the premium carbon frame and ensures an inconspicuous look. Powered by the Generation 5 Bosch CX motor, the Style FS Prime provides you with perfect support in every situation. With the 800 Wh PowerTube battery, even extra-long tours over several days are no problem. You are also perfectly informed and protected with the sizeable Kiox 500 display and the pre-installed Bosch ConnectModule. The icing on the cake in terms of comfort is the electronic Di2 Cues gearstick. In auto mode, it takes care of all the shifting for you - simply set the desired cadence and start pedalling.
Features of the KTM Macina Style FS Prime
- Full-suspension step-through trekking eBike
- Made from premium carbon fibre
- Bosch Perf. CX Gen.5 motor - 85 Nm
- Bosch PowerTube 800 Wh - removable
- Bosch Kiox 500 + LED Remote
- Bosch ConnectModule
- Electric Shimano Cues Di2 1x11 gears with Auto-Shift
eBike24 recommends: The KTM Macina Style FS Prime is the perfect comfort eBike. If you are looking for a step-through bike with damper, you will find it with the Style FS Prime.
E-Bike Types: | SUV E-Bike, Trekking e-Bikes |
Model year: | 2025 |
Battery capacity: | 800 Wh - 899 Wh, Dual Battery compatible |
Drive system: | Bosch drive |
Manufacturer: | KTM |
Frame type: | Low-entry / Wave |
Derailleur/drive type: | Derailleur - chain drive |
Battery option: | Dual Battery compatible |
Battery position: | Intube battery / frame integrated |
Bosch System: | Bosch Performance Line CX from 2025 Smart System |
Frame: | Macina Style Performance Carbon |
Fork: | Suntour X1 32 AIR 29" LOR 100mm taper |
Battery: | Bosch PowerTUBE 800Wh horizontal |
Tyres: | Schwalbe Green Marathon Perf. GreenGuard 50-622 |
Saddle: | Selle Royal Lookin Lady Evo |
Seat post: | KTM Line II Dropper 30.9 |
Carrier: | Racktime Alumee (Snap-it 2.0 + Monkeyload) |
Weight: | 29.2 kg |
Item: | KTM Macina Style FS Prime - 2025 |
Colour: | STEEL BLUE MATT |
Stem: | KTM Line adjust. 0-60° ICR |
Display: | Bosch KIOX 500 TFT display |
Side stand: | KTM 28" bike stand MY2025, adjustable |
Wheels: | KTM Line - Shimano TC500B | KTM Line - Shimano TC600B |
Damper: | Suntour EDGE-EVO 2CR 190x45 |
Spring travel: | Front: 100mm | Rear: 100mm |
Grips: | Ergon GP30 |
Motor: | Bosch PERFORMANCE CX BDU3840 25km/h / 85Nm |
Rear light: | B&M Dart brex |
Front light: | B&M IQ-XM 120-170Lux HighBeam |
Pedal: | MTB pedal flat VPE-527 alloy |
Wheel size: | 28" |
Handlebar: | KTM Team II Rizer15 720mm |
Crank: | KTM E-Team2 ISIS 170mm Q8 |
Cassette: | Shimano LG400-11 / 11-50 |
Rear derailleur: | Shimano CUES Di2 U8050-11 SGS shadow |
Chain: | Shimano LG500 |
Shift lever: | Shimano Di2 EN605 wireless |
Charger: | Bosch Standard Charger 4A |
Disc brakes: | Shimano RT64 CL 180 / EM600 CL 180 magnet |
Control unit: | Bosch LED Remote |
Brake: | Shimano MT402 (3-F) / MT420 4-piston |
GPS: | Bosch ConnectModule |
