KTM Macina Chacana 892 LFC - 2025

KTM Macina Chacana 892 LFC - 2025
5,299.00€

Prices incl. VAT plus shipping costs

  • 10357-001
  • 1250031100
  • 9008594493308

Frame Size:

The KTM Macina Chacana 892 LFC 2025 is a versatile e-mountainbike with high-quality components. The drive unit is the Bosch Performance CX, which provides powerful support up to a speed of 25 km/h. The Bosch PowerTube 800Wh is integrated into the down tube, allowing you to go on extended tours. The Bosch Intuvia 100 display is also mounted on the handlebar. This allows you to view ride data such as speed and kilometres travelled. The display is controlled via the Bosch LED Remote. The Fully E-MTB is designed for use on trails and uneven terrain. The FOX Float Rhythm damper and the Suntour XCR34X Air 29" fork ensure a comfortable ride and reliably absorb shocks. The special feature of the KTM Macina Chacana 892 LFC is that it has trekking components in addition to the classic mountain bike equipment. Thanks to the Racktime Alumee Rails luggage rack, the Litemove SE-150 headlight and the Racktime aluminium 72mm mudguard, the fully e-mountain bike is also ideal for everyday use.

eBike24 recommends: The Macina Chacana 892 LFC is suitable for people who use the fully e-MTB both on trails and in everyday life.

Features of the KTM Macina Chacana 892 LFC - 2025

  • Bosch Performance CX
  • Bosch PowerTube 800Wh
  • Bosch Intuvia 100 + Bosch LED Remote
  • FOX Float Rhythm damper
  • Suntour XCR34X Air 29" fork
  • KTM 28" bike stand MY2025
  • E-MTB with front light, luggage rack & mudguard
Specifications
E-Bike Types: E-Mountainbike (e-MTB), Fully e-MTB
Model year: 2025
Battery capacity: 800 Wh - 899 Wh
Drive system: Bosch drive
Manufacturer: KTM
Derailleur/drive type: Derailleur - chain drive
Battery position: Intube battery / frame integrated
Bosch System: Bosch Performance Line CX from 2025 Smart System
Frame: Macina Chacana Alloy 6061 SLL-E
Fork: Suntour XCR34X Air 29" 2CR 130mm taper
Battery: Bosch PowerTUBE 800Wh horizontal
Tyres: Schwalbe Johnny Watts Perf. DD RaceGuard 60-622 Reflex
Saddle: Selle Royal Lookin Athletic Evo
Seat post: KTM Comp II Dropper internal 34.9
Carrier: Racktime Alumee Rails
Weight: 28.4 kg
Item: KTM Macina Chacana 892 LFC - 2025
Colour: OLIVE PEARL
Stem: KTM Team Trail35
Display: Bosch INTUVIA LCD Display
Side stand: KTM 28" bike stand MY2025, adjustable
Wheels: Mavic E-Crossride 29
Damper: FOX Float Rhythm 2Pos 230x57.5
Spring travel: Front: 130mm | Rear: 125mm
Grips: Ergon GA30
Motor: Bosch PERFORMANCE CX BDU3840 25km/h / 85Nm
Front light: Litemove SE-150 150Lux down
Pedal: MTB pedal flat VPE-527 alloy
Wheel size: 29"
Handlebar: KTM Comp Trail35 rizer15 760mm
Crank: KTM E-Team2 ISIS 170mm Q8
Cassette: Shimano LG400-11 / 11-50
Rear derailleur: Shimano CUES U6000-11/10 LG shadow+
Chain: KMC e11 Sport EPT eBike
Shift lever: Shimano CUES U6000-11 display
Charger: Bosch Standard Charger 4A
Disc brakes: Shimano RT64 CL 203 / RT64 CL 180
Control unit: Bosch LED Remote
Brake: Shimano Deore M6100 / M6120 4-piston
