Prices incl. VAT plus shipping costs
- Item number: 8294-001
- Manufacturer Part Number: 1230086503 / 023343503
- EAN: 9008594471788
With the KTM Macina Aera 772 LFC you get a comfortable as well as sporty city SUV with off-road MTB equipment. Thanks to Suntour XCR 34 suspension fork with 80 mm travel, Shimano Deore gears and thick Schwalbe Johnny Watts tires, you can easily break out of the urban routine and let off steam even on rough terrain. A Bosch Smart System drive with 85 Nm of torque and a 750 Wh Akkuk provide constant thrust. In addition, the Aera 772 LFC comes with mudguards, Litemove lighting system and Racktime rack with pannier holder. Thus, one is well equipped for extra long weekend tours with luggage.
Features of the KTM Macina Aera 772 LFC - 2024:
- 27.5 inch Macina MTB low entry frame aluminum frame.
- Bosch Performance CX Smart System drive, 85 Nm
- Bosch Powertube 750 Wh battery
- Bosch Kiox 300 Display + LED Remote
- Shimano Deore M5130 10-speed gears
- Suntour XCR 34 air suspension fork 80 mm travel
- Racktime luggage rack, Litemove lighting system, Ergon grips and much more.
- Swallow Johnny Watts performance tires 65-584 DD
Ebike24 recommends: The KTM Macina Aera 772 the perfect partner for the city as well as for trips in nature. With the Aera 772 LFC you get an SUV e-bike, which is thanks to high-quality eMTB equipment and the latest Bosch technology for every use.
E-Bike Types: | E-Mountainbike (e-MTB), SUV E-Bike, Trekking e-Bikes |
Model year: | 2023 |
Battery capacity: | 700 Wh - 799 Wh |
Drive system: | Bosch drive |
Manufacturer: | KTM |
Frame type: | Low-entry / Wave |
Derailleur/drive type: | Derailleur - chain drive |
Bosch System: | Bosch Performance Line CX from 2022 Smart System |
Battery position: | Intube battery / frame integrated |
Frame: | Macina Trekking Onroad Aluminum 6061 PT750Wh Bosch Gen.4 / T-2940 |
Fork: | Suntour XCR 34 Air 27.5" LOR 80mm 15x110 taper |
Battery: | Bosch PowerTube 750 Wh Smart System horizontal |
Tyres: | Schwalbe Johnny Watts Perf. Folding 65-584 DD |
Saddle: | Selle Royal Lookin+ |
Seat post: | KTM Team 30.9/300 |
Carrier: | Alumee light (snap-it 2.0) |
Item: | KTM Macina Aera 772 LFC 2024 |
Colour: | Machine Grey (black+silver) |
Model year: | 2024 |
Stem: | KTM Line adjust. 0-60° internal |
Display: | Bosch Kiox 300 |
Side stand: | KTM 28" adjustable |
Wheels: | front: KTM Line - Shimano MT410B CL 32H 110-15TA Ryde Rival30 32H 584x30C DT Champion 2.0 black | rear: KTM Line - Shimano Deore M6000 CL 32H 135-5QR Ryde Rival30 32H 584x30C DT Alpine II 2.34 black |
Mudguard: | Racktime Alu 72mm |
Spring travel: | 80 mm |
Grips: | Ergon GP1 SD |
Motor: | Bosch Performance CX Gen.4 Smart System - 85 Nm |
Headset: | Acros AICR internal 1.1/8"-1.5" angle limit |
Rear light: | B&M Xeltec integrated in the Fender |
Front light: | Litemove SE-150 LED 150Lux |
Pedal: | MTB-Pedal flat VPE-527 Aluminum |
Wheel size: | 27,5" |
Handlebar: | KTM Team rizer15 680mm |
Permissible total weight: | 147 kg |
Crank: | KTM E-COMP ISIS 170mm Q16 |
Cassette: | Shimano LG400-10 / 11-43 |
Rear derailleur: | Shimano Deore M5130-10 LG shadow+ |
Chain: | Shimano LG500 |
Shift lever: | Shimano Deore M5130-10 display |
Charger: | Bosch Smart System Standard Charger - 4A |
Disc brakes: | Tektro TR-45 2.3mm CL 180 / 180 |
Control unit: | Bosch LED Remote |
Brake: | Tektro HD-M535 4-Piston |
GPS: | No - Bosch ConnectModule Ready |
