Flyer ebike light converter for models until 2011

Preview: Flyer ebike light converter until 2011

Preview: Flyer ebike light converter until 2011 - Connection diagram

Flyer ebike light converter until 2011 - Connection diagram

40.90€

Prices incl. VAT plus shipping costs

Item number: 1303
Manufacturer Part Number: 500539

Delivery time to Germany 1-2 business days

Close menu

Until 2011, the light converter was required on electric bikes from Flyer to convert the usual system voltage of 26-volt DC to 6-volt.

The component was used on Flyer models up to the 2011 or 2012 model year and on high-speed electric bike models, which were generally not compatible with hub dynamos.

In 2012, Busch und Müller launched the new e-bike or pedelec-compatible e-headlights, which had an internal "light converter". Since these new e-bike headlights have 2 power source inputs and cover a voltage range of 6 volts - 42 volts, the light converter was no longer installed from 2012.

The communication between motor or battery (26V) and lighting system, as well as between hub dynamo (6V) and lighting system is since 2012 directly on the headlight.

Drive system:	Panasonic drive
Manufacturer:	Flyer, Panasonic
Panasonic System:	Panasonic Motor central Premium 26 V
Item:	Flyer ebike light converter until 2011
Scope of delivery:	1x light converter until 2011
Manufacturer:	Biketec Flyer
Colour:	green / black / grey
Model year:	till 2011
Compatibility:	E-Bikes with Panasonic 26-Volt drive
